Device Interfaces | • 8 x Gigabit Ethernet LAN ports, 1 x power connector |
Standards | • IEEE 802.3 10BASE-T Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE 802.3ab 1000BASE-T Gigabit Ethernet • ANSI/IEEE 802.3 NWay auto-negotiation • IEEE 802.3x Flow Control • IEEE 802.3az Energy-Efficient Ethernet (EEE) |
Advanced Features | • Green Ethernet • 16 Gbps switching fabric • Auto MDI/MDIX crossover for all ports • Secure store-and-forward switching scheme • Full/half-duplex for Ethernet/Fast Ethernet speeds • IEEE 802.3x Flow Control • Supports 9KB Jumbo Frame • Supports IEEE 802.1p QoS |
Data Transfer Rates | • Ethernet: • 10 Mbps (half duplex) • 20 Mbps (full duplex) Fast Ethernet: • 100 Mbps (half duplex) • 200 Mbps (full duplex) Gigabit Ethernet: • 2000 Mbps (full duplex) |
Transmission Method | • Store-and-forward |
MAC Address Table | • 4K |
MAC Address Learning | • Automatic Update |
Packet Buffer | • 192 KB |
LED Indicators | • Per port: Link/Activity • Per device: Power |
Media Interface Exchange | • Auto MDI/MDIX for all ports |
Dimensions | • 142 x 75 x 22.45 mm |
Weight | • 117 g |
Power | • 5 V/1 A Power Adapter |
MTBF | • 1,468,984 hours |
