Dimensions (W × H × D)105 mm × 27.6 mm × 83.1 mm (4.1” × 1.1” × 3.3”)
ShellMetal material, fan-free design
Gross Weight0.76 kg (1.67 lb)
Net Weight0.27 kg (0.58 lb)
Operating Temperature–10 °C to 55 °C (14 °F to 131 °F)
Operating Humidity5% to 95% (no condensation)
Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
Storage Humidity5% to 95% (no condensation)
Power Supply48 VDC, 0.8 A
Power Consumption In Idle3 W
Max. Power Consumption38 W
Approval
EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 18)
SafetyUL (UL 62368-1); CB (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2028)
ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2017)
