Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding ModeStore-and-forward switching
MAC Address Table8 K
Switching Capacity36 Gbps
Packet Forwarding Rate26.784 Mpps
Internal Cache4.1 Mbits
PoE Power Supply
PoE StandardIEEE 802.3af, IEEE 802.3at
PoE Power PinEnd-span: 1/2(-), 3/6(+)
PoE PortPorts 1 to 16
Max. Port Power30 W
PoE Power Budget125 W
General
Dimensions (W × H × D)440 mm × 44 mm × 220.8 mm (17.3” × 1.7” × 8.7”)
ShellMetal material, fan-free design
Gross Weight2.50 kg (5.51 lb)
Net Weight3.57 kg (7.87 lb)
Operating Temperature–10 °C to 55 °C (14 °F to 131 °F)
Operating Humidity5% to 95% (no condensation)
Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
Storage Humidity5% to 95% (no condensation)
Power Supply100 to 240 VAC, 50/60 Hz, 2.5 A (Max)
Power Consumption In Idle25 W
Max. Power Consumption150 W
Approval
EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 12)
SafetyUL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2022)
ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2011)
