MERCUSYS AC10 AC1200 Wireless Dual Band Router

IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz

2.4 GHz, 5 GHz

Up to 300 Mbps on 2.4 GHz, 867 Mbps on 5 GHz

11g 6Mbps: -96dBm
11g 54Mbps: -78dBm
11n HT40 MCS7: -74dBm
11n HT20 MCS7: -71dBm
11a 6Mbps: -97dBm
11a 54Mbps: -79dBm
11ac VHT20 MCS8: -74dBm
11ac VHT40 MCS9: -70dBm
11ac VHT80 MCS9: -65dBm

2.4 GHz < 20dBm (EIRP)
5 GHz < 23dBm (EIRP)

WEP, WPA / WPA2, WPA-PSK / WPA2-PSK


Enable/Disable Wireless Radio, WMM

Router Mode, Access Point Mode

Dynamic IP/Static IP/PPPoE/L2TP/PPTP

Access Control, Local Management, Remote Management


Server, DHCP Client List

Port Forwarding, Port Triggering, UPnP, DMZ

SPI Firewall, IP and MAC Address Binding

2.4 GHz Guest Network, 5 GHz Guest Network

4.5 × 3.7 × 1.0 in (114 × 94 × 26 mm)

1× 10/100 Mbps WAN Port
2× 10/100 Mbps LAN Ports

Reset/WPS Button

9V/0.85A

4× 5 dBi Fixed Omni-Directional Antennas

AC1200 Wireless Dual Band Router AC10
Power Adapter
Quick Installation Guide
RJ45 Ethernet Cable

Operating Temperature: 0°C~40°C (32°F~104°F)
Operating Humidity: 10%~90% Non-Condensing
Storage Humidity: 5%~90% Non-Condensing
